Magnification 2.3-18
Effective objective lens diameter (mm) 18.4-56
Exit pupil diameter (mm) 8.1-3.1
Exit pupil distance (mm) (Eye relief) 95
Field of view (ft/100 yds / m/100 m) 55.8-6.9 / 18.6-2.3
Field of view (degrees) 10.6-1.3
Field of view, apparent (degrees) 24
Dioptric compensation (dpt) -3
to +2
Light transmission (%) 93
Twilight factor acc. to ISO 14132-1 6.5-31.8
Impact point corr. per click (in/100 yds / mm/100 m) 0.36 / 10
Max. elevation / windage adjustment range (in/100 yds /
m/100 m) 64.8/36.0 / 1.8/1.0
Parallax correction (yds / m) 55-∞ / 50-∞
Objective filter thread M
58x0.75
Technical Data
Length (in / mm) 14.3
/ 364
Weight (oz / g) 25.6 /
725
Central tube diameter (in / mm) 1.18 / 30
Functional temperature -4
°F to +131 °F (-20 °C / +55 °C)
Storage temperature -22
°F to +158 °F (-30 °C / +70 °C)
Submersion tightness 13
ft / 4 m water depth (inert gas filling)
Illumination unit
Brightness levels Twilight:
0 - 32 / Day: 33 - 64
Operating time (h) Twilight
factor at medium brightness: 1,400; daylight factor at medium brightness: 180
