Delivery scope contoured
neoprene carrying strap, front lens caps, eyepiece caps, cordura case
Magnification 8 x
Front lens diameter 32
mm
Exit pupil 4
mm
Twilight factor 16
Field of view at 1,000 m / Field of view at 1,000 yds 135 m
404 ft
Eye-relief 13.3
mm
Objective angle of view 7.7°
Close focusing distance approx.
2.1 m/7.2 ft
Diopter compensation ±
4 diopters
Automatic diopter compensation ADC™ yes
Eyepieces for eyeglass wearers yes, removable, with 4 click stops
Adjustable interpupillary distance 52 – 74 mm
Focusing internal
focusing via central focusing device
Prism system roof
prism with phase correcting coating P40 and HighLux-System HLS™
Coating HDC™
multicoating and Leica AquaDura™ lens coating
Watertightness waterproof
to a depth of 5 m/16.5 ft
Housing magnesium,
nitrogen-filled
Dimensions (W x H x D) 116
x 116 x 56 mm
4.57 x 4.57 x 2.2 in
Weight approx. 535 g /
18.9 oz
Order No. Accessories
Neoprene carrying strap, contoured included
Floating carrying strap, orange 42 163
Tripod adapter 42 220
