Thermal Imaging Performance
Sensor Type: 640 x 480 VOx microbolometer
Fields of View: 9.4°(H) x 7.5° (V)
Spectral Band: 7.5-13.5 µm
Automatic Features: Contrast, Brightness
System Features
Silent Operation: Inaudible beyond 1 m
Bore Sight Retention: Holds boresight through extensive rounds of firing on a variety of weapon platforms
Outputs
Video: Built in Display VGA monochrome and external video out
Power
Power Requirements: 2/3 AA or 1/2 DL123
Battery Life: Approximately 6 hours continuous use
Environmental
IP Rating: IP 68 (66ft. seawater, 2 hours)
Operating Temp: -40°C to +49°C (-40°F to +120°F)
Storage Temp: -40°C to +71°C (-40°F to +160°F)
Shock and Vibe: Per MIL-STD-810F
Dimensions, Weight & Mounting
Dimensions (Lens Cover Off): 6.8" L x 2.8" W x 3.5" H
Weight: 1.5 lbs with batteries and lens covers
Mounting: Mil-Std-1913 Rail Mount
Interfaces
Command and Control
Joystick: Palette, Polarity, Zoom, Digital Detail EnhancementBrightness/Contrast Windage/Elevation and Menu / Menu: Calibration, Display, Mode (Clip-on), Weapon, ExternalVideo
Standard Package
Batteries:T70 with adjustable quick detach throw lever mount, coupling lightshroud /eye relief, video outputcable, remote control pad, batteries, operators manual, graphic training aid, lens cleaning kit, and softcarrying case
