Thermal Imaging Performance
Sensor Type 320 x 240 VOx microbolometer
Fields of View 9.33° (h) x 7° (v)
Spectral Band 7.5-13.5 µm
Automatic Features Contrast, brightness, STACE? (digital image enhancement)
System Features
Silent Operation Inaudible beyond 1 m
Bore Sight Retention Holds boresight through extensive rounds of firing
Outputs
Video Built in Display VGA monochrome and RS-170 output
Power
Power Requirements Three CR123 batteries
Battery Life Approximately 9 hours continuous use
Environmental
IP Rating IP 68
Operating Temp -40°C to +75°C (-40°F to +131°F)
Storage Temp -50°C to +85°C (-58°F to +149°F)
Dimensions, Weight & Mounting
Dimensions (Lens Cover Off) 5.3" L x 3.5" W x 4.0" H
Weight 24 oz with batteries, lens covers and rail mount
Mounting Picatinny Rail Mount
Interfaces
Command and Control Auto/manual gain/level, polarity, manual NUC, 2x, 4x digital zoom
Standard Package
Laser Pointer Red Visible or 30mW IR 850nm and safety mode of 0.5mW
Batteries 3 each, CR123, fit into plastic sleeve for quick removal and replacement
