Detector 12μm VOx Uncooled Focal Plane Array
Resolution 640 × 512
NETD Less than 20 mK (25°C, F# = 1.0)
Refresh Rate 50 Hz
Lens System 35 mm; F0.9 / 60 mm; F1.1
Magnification 2× - 16× / 3× - 24×
Field of View 12.5° × 10.0° / 7.3° × 5.9°
Diopter Adjustment -5 to +5 diopters
Focus Range 7 m to infinity / 10 m to infinity
Exit Pupil 6 mm
Eye Relief 45 mm
Digital Zoom 1×, 2×, 4×, 8×
Detection Range (6’ object) 1800 m/yd / 3000 m/yd
Display 0.39-inch, OLED, 1024×768
Palettes Black hot, White hot, Red hot, Fusion
Flat Field Correction Auto, Manual, External Correction
Scene Mode Cold, Warm
Boresight Adjustment Digital Controlled
Video/Audio Recording Yes/Yes
Image Capture Yes
Standby Modes Yes
Storage Built-in EMMC (16 GB)
PIP Yes
Defective Pixel Correction Yes
WiFi Hotspot Yes
Hot Track Yes
Reticle 10 types, 4 colors, on/off
Distance Measurement Yes (Stadiametric)
Shot Activated Recording (SAR) Yes
Battery Type Battery Replaceable and Rechargeable Li-ion Battery
Battery Life (Operating, 20°C) ≥ 11 h (25°C, hotspot off)
External Power Supply 5 VDC, 2 A, USB Type-C
Operating Temperature Range -30°C to +55°C (-22°F to 131°F)
Protection Level IP67
Max. Recoil 1000 g/0.4 ms
Weight (w/o mount and battery) 0.84 kg (1.85 lb)
Dimensions (w/o mount) 254 × 80 × 68 mm (10.0 × 3.1 × 2.7 in)
|
