Magnification
3.5× - 56×
Interpupillary Distance
60 mm to 70 mm
Digital Zoom
1×, 2×, 4×, 8×, 16×
Detection Range
2,600 m/yd (6’ object)*
Flat Field Correction (FFC)
905 nm (Class 1)
Palettes
Optical, White Hot Thermal, Black Hot Thermal, Red Hot Thermal, Image Fusion
Diopter Adjustment
0.39-inch, OLED, 1024×768
Battery Type
Three 18650 batteries
Image Sensor
Vanadium Oxide Uncooled Focal Plane Array
Resolution
640×512
Pixel Pitch
12 μm
Response waveband
8 μm to 14 μm
NETD
Less than 20 mK (25°C, F#=1.0)
Field of View
8.7° × 7.0°
Aperture
F0.9
Lens (Focal Length)
Less than 20 mK (25°C, F#=1.0)
Monitor
0.39-inch, OLED, 1024×768
Storage
Built-in memory module (64 GB)
Snapshot
JPEG, 1600x1200
Battery Operating Time
Up to 8 hours
Battery Capacity Display
Yes
Protection level
IP67
Mounting
1/4”-20 UNC
Cable Output
USB Type-C port
Accessories (Supplied)
Battery Charger, Power Cable, Lens Cloth, Two Wrist Straps, Neck Strap, Six 18650 Batteries, Power Adapter, User Manual, Carrying Case
Dimension (LxWxH)
217 × 155 × 88 mm (8.5 × 6.1 × 3.5 in)
Weight
1.12 kg ( 2.5 lb)
Storage temperature range
-40°C to 70°C (-40°F to 158°F)
Picture In Picture Mode (PIP)
Yes
Video Recording
MP4, 1600x1200
Measuring Distance of Laser Rangefinder
Max. 1,000 m
Laser
Wavelength
905 nm (Class 1)
Eye relief
15 mm
External power supply
DC 5V/2A, Max.10W, Type-C port
|
