Palettes
Black Hot, White Hot, Red Hot, Fusion
Reticle
5 types, 4 colors, on/off
Drop Test Height
1.5 m (4.9 ft)
Boresight Adjustment
Digital Controlled
Boresight Increment
0.15 mil / 0.51 MOA
Scene Mode
Yes
Picture In Picture Mode (PIP)
Yes
Hotspot
Yes
Digital Magnification
2.5x - 20x
Detector type
12 μm VOx Uncooled Focal Plane Arrays
Response Waveband
8 μm to 14 μm
FFC (Flat Field Correction)
Auto, Manual, External Correction
Highest Temperature Spot Tracking
Yes
Standby Mode
Yes
Refresh rate
Sensor 50Hz / OLED 50Hz
Aperture
F1.0
Resolution
640 × 512
Laser Rangefinder
Up to 600 m, ±2 m accuracy
Laser Wavelength
905 nm
Detection Range (6' object)
2,500m/yd
Lens (focal length)
50 mm
Field of view (H × X)
8.78° × 7.03°
Digital zoom
1x, 2x, 4x, 8x
Monitor
1024x768, 0.39 inch, OLED
Eye relief
45 mm
Storage
Built-in 16 GB EMMC
Record Video
On-board video recording
Capture Snapshot
Yes
Battery Type
One 18650 (3.7V) Lithium Rechargeable Batteries
CVBS Output
Yes (via USB)
Battery Operating Time
Up to 4.5 hours
Battery Capacity Display
Yes
External power supply
5 VDC/2 A, USB Type-C
Operating Temperature Range
-20°C to 55°C (-4°F to 131°F)
Weight
722 g (1.59 lb)
Overall Dimensions
210 x 74 x 109 mm (8.3 × 2.9 × 4.3 in)
Protection Level
IP67
Magnification
2.5x
|
