Palettes Palettes Black Hot, White Hot, Red Hot, Fusion
Reticle 5 types, 4 colors, on/off
Drop Test Height 1.5 m (4.9 ft)
Boresight Adjustment Digital Controlled
Boresight Increment 0.22 mil / 0.73 MOA
Scene Mode Yes
Picture In Picture Mode (PIP) Yes
Hotspot Yes
Digital Magnification 2x - 16x
Detector type 12 μm VOx Uncooled Focal Plane Arrays Response Waveband 8 μm to 14 μm
FFC (Flat Field Correction) Auto, Manual, External Correction
Highest Temperature Spot Tracking Yes
Standby Mode Yes
Refresh rate
Sensor 50Hz / OLED 50Hz
Aperture
F1.0
Resolution
640x512
Laser Rangefinder
Up to 600 m, ±2 m accuracy
Laser Wavelength
905 nm
Detection Range (6' object)
1,750m/yd
Lens (focal length)
35 mm
Field of view (H × X)
12.52° × 10.03°
Digital zoom
1x, 2x, 4x, 8x
Monitor
1024x768, 0.39 inch, OLED
Eye relief
45 mm
Storage
Built-in 16 GB EMMC
Record Video
On-board video recording
Capture Snapshot
Yes
Battery Type
One 18650 (3.7V) Lithium Rechargeable Batteries
CVBS Output
Yes (via USB)
Battery Operating Time
Up to 4.5 hours
Battery Capacity Display
Yes
External power supply
5 VDC/2 A, USB Type-C
Operating Temperature Range
-20°C to 55°C (-4°F to 131°F)
Weight
652 g (1.44 lb)
Overall Dimensions
200 x 66 x 109 mm (7.8 × 2.6 × 4.3 in)
Protection Level
IP67
Magnification
2x
|
