Palettes
Black Hot, White Hot, Red Hot, Fusion
Reticle
5 types, 4 colors, on/off
Boresight Adjustment
Digital Controlled
Boresight Increment
0.15 mil / 0.51 MOA
Distance Measurement
Yes (Stadiametric)
Scene Mode
Jungle, Recognition
Picture In Picture Mode (PIP)
Yes
Video Recording
Yes
Defective Pixels Correction (DPC)
Yes
Uniformity Correction
Auto, Manual, External Correction
Digital Magnification
2.5x - 20x
Detector type
12μm, Uncooled, 50 Hz, < 35 mK (25°C, F# = 1.0)
Standby Mode
Yes
Resolution
640 × 512
Detection Range (6' object)
2600 m/yd
Lens system
50 mm; F/1.0
Field of view (H × X)
8.8° × 7.0°
Digital zoom
1×, 2×, 4×, 8×
Diopter adjustment range
-5 to +5 dpt
Eye relief
≥ 60 mm
Display
1024×768, 50 Hz, OLED
Storage
64 GB EMMC
Battery Type
Two 18650
Rechargeable Batteries (built-in) and one CR123 Battery
CVBS Output
Yes (via USB)
Battery Life (Operating)
Up to 13 hr
Power supply
5 VDC/2 A, USB Type-C Supports QC3.0
Operating Temperature Range
-30°C to +55°C (-22°F to +131°F)
Degree of Protection
IP67
Weight
970 g ( 2.14 lb)
Overall Dimensions
420 × 78 × 82 mm (16.5 × 3.1 × 3.2 in)
Magnification
2.5×
|
